Fence frames industrial automation welding robot

This fence frames industrial automation welding robot places the robot and welding system in the center and places two sets of positioners on both sides of the robot, which not only ensures the safety of the system but also not affects the use of the entire.This fence frames industrial automation welding robot is widely used in welding various metal frame structures such as guardrails, metal door and window frames, scaffolding parts, pasture fences, isolation nets, animal cages, table frames, medical bed frames, etc.

Application:

Construction, transportation, medical care, animal husbandry, furniture, logistics, etc.

Parameter:

Arc welding robot body:FD-V6 OTC 2suits ;
control cabinet: FD11 OTC 2suits;
transformer: 10KV OTC 2suits.

Advantage
Structure
Parameter
Video
Cases
Online Message

Advantage

1. The core components are imported from Japan, and the performance is stable and excellent:
The robot body and its core components are imported from Japan OTC. The accuracy of the pre-order workpiece is quite small. the double-drive wire feeder ensures the smooth welding process, good weld quality, and beautiful appearance.

2. Twenty-three years of technology precipitation, stable structure system:
23 years of experience in R&D and manufacturing of intelligent welding equipment technology, multi-generation product process accumulation and upgrading, mature system, compact structure, fast operation and accurate positioning.

3. Improve production efficiency and economic benefits significantly:
The whole system adopts double-station welding robot. Welding, disassembly, clamping and handling can be completed independently without mutual interference. It can realize welding all day and improve production efficiency and economic benefits greatly.

Structure

a) The workpiece be clamped on the servo positioner at the A end → the double welding robot starts the welding work at the same time → the workpiece of the B end is clamped while the robot welds the workpiece the A side→ After the workpiece at A end is welded,then the welding robot turns to the B end workpiece → The workpiece is disassembled and assembled manually at A side while the robot welds the B-end workpiece.

b) This cycle can save a lot of manpower and material resources. and the entire workstation system is structurally stable to meet 24 hours of continuous operation. The overall layout of the system is as follows (this figure is for reference only, the final acceptance is subject to the design drawings).

Parameter

Serial number	Name	Model and configuration	Manufacturer	QTY	Remark
1、Robot system
1	Arc welding robot body	FD-V6	OTC	2 suit
2	Control cabinet	FD11	OTC	2 suit
3	Teaching Demonstration	T/P	OTC	2 suit
4	transformer	10KV	OTC	2 suit
2、Welding system
1	Welding power supply	DM350	OTC	2 suit
2	Wire Feeder		OTC	2 suit
3	Robot special welding torch		OTC	2 suit
4	Wire Feeder	Double drive	OTC	2 suit
5	Welding accessories		OTC	2 suit
6	Gas regulator	36V	OTC	2 suit
7	Reservation control box		OTC	2 suit
3、other equipment
1	Robot base		Kehui technology	2 suit
2	Servo positioner		Kehui technology	2 suit
3	Fixture		Kehui technology	2 suit
4	Welding torch cleaner			1 suit
4、control system
1	Control appliance		Kehui technology	1 suit
2	External control box		Kehui technology	2 suit
3	Station wiring			1 suit
